物理特性/Physical Characteristics

尺寸 Dimensions:

135mm x 105mm x100mm

重量 Weight:

305g

電壓 Voltage:

5V DC

工作電流 Working Current：

300mA

待機電流 Standby Current：

100mA

峰值電流 Peak Current：

350mA

性能指標/Performance Characteristics

傳感器像素 Image (Pixels):

640 pixels (H)x 480 pixels (V)

光源 Light Source:

 Illumination：6500K LED

視場角 Field of View:

40.5°(Horizontal)，31°(Vertical)

旋轉傾斜偏轉 Roll / Pitch / Yaw:

360°, ±65° , ±60°

打印對比度Print Contrast:

20% minimum reflective difference

接口支持 Interfaces Supported:

USB、RS232(選配)

運動容差Motion Tolerances:

>2m/s

解碼能力/Symbology Decode Capability

一維條碼/1-D:

UPC, EAN,Code 128,Code 39, Code 93, Code 11, Matrix 2 of 5, Codabarlnterleaved 2 of 5, Mis Plessey, GSl DataBar, China Postal, Korean Postal,etc

二維條碼/2-D:

PDF417,MicroPDF417, Data Matrix,Maxicode,QR Code,MicroQR, AztecHanxin, etc.

條碼精度Minimum Resolution:

≥3.9 mil

用戶環境參數/User Environment

工作溫度 Operating Temperature:

-20°C to 50°C

存儲溫度 Storage Temperature:

-30°C to 80°C

濕度 Humidity:

0% to 95% relative humidity,non-condensing

抗震性 Shock Specifications:

Designed to withstand 1.2m(5’) drops

環境光免疫 Ambient Light Immunity:

0-100,000 Lux.

解碼范圍/Decode Ranges

PDF417(6.88mil)

0mm-50mm

UPCA(13mil)

5mm-110mm

QR(20mil)：

0mm-100mm

Performance may be impacted by bar code quality and environmental conditions
